| Model： | 6kW-32 | 9kW-32 | 12kW-32 | 15kW-32 | 18kW-32 | 12kW-32 | 15kW-32 | 18kW-32 | ||
| Heating Capacity Range | kW | 2.0-6.5 | 3.0-9.14 | 4.0-12.1 | 5.0-15.3 | 6.0-18.2 | 4.0-12.1 | 5.0-15.3 | 6.0-18.2 | |
| Heating (A7/6℃,W30/35℃) | eating Capacity | kW | 6.5 | 9.14 | 12.10 | 15.30 | 18.2 | 12.1 | 15.30 | 18.20 |
| Power Input | kW | 1.34 | 2.04 | 2.73 | 3.26 | 4.00 | 2.73 | 3.26 | 4.00 | |
| Current | A | 5.83 | 8.87 | 11.87 | 14.16 | 17.39 | 4.61 | 5.50 | 6.75 | |
| COP | W/W | 4.78 | 4.48 | 4.43 | 4.70 | 4.55 | 4.43 | 4.70 | 4.55 | |
| Heating (A-12℃,W36/41℃) | Heating Capacity | kW | 3.78 | 5.25 | 7.4 | 9.30 | 10.85 | 7.4 | 9.30 | 10.85 |
| Power Input | kW | 1.45 | 2.14 | 3.06 | 3.50 | 4.3 | 3.06 | 3.50 | 4.3 | |
| COP | W/W | 2.61 | 2.45 | 2.42 | 2.66 | 2.52 | 2.42 | 2.66 | 2.52 | |
| Heating (A7/6℃,W40/45℃) | Heating Capacity | kWH | 6.1 | 8.8 | 12.17 | 15.25 | 18.21 | 12.17 | 15.25 | 18.21 |
| Power Input | kW | 1.64 | 2.55 | 3.54 | 4.14 | 5.09 | 3.54 | 4.14 | 5.09 | |
| COP | W/W | 3.72 | 3.45 | 3.44 | 3.68 | 3.58 | 3.44 | 3.68 | 3.58 | |
| Heating (A7/6℃,W47/55℃) | Heating Capacity | kW | 5.33 | 7.75 | 10.24 | 12.37 | 14.73 | 10.24 | 12.37 | 14.73 |
| Power Input | kW | 1.71 | 2.83 | 3.45 | 3.83 | 4.7 | 3.45 | 3.83 | 4.7 | |
| COP | W/W | 3.12 | 2.74 | 2.97 | 3.23 | 3.13 | 2.97 | 3.23 | 3.13 | |
| Cooling (A35/24℃,W23/18℃) | Cooling Capacity | kW | 6.25 | 8.99 | 11.00 | 14.97 | 17.82 | 11.00 | 14.97 | 17.82 |
| Power Input | kW | 1.54 | 2.41 | 3.08 | 4.01 | 4.92 | 3.08 | 4.01 | 4.92 | |
| Current | A | 6.70 | 10.48 | 13.39 | 17.42 | 21.39 | 5.20 | 6.76 | 8.31 | |
| EER | W/W | 4.05 | 3.73 | 3.57 | 3.74 | 3.62 | 3.57 | 3.74 | 3.62 | |
| Cooling (A35/24℃,W12/7℃) | Cooling Capacity | kW | 5.16 | 6.86 | 9.44 | 12.10 | 14.95 | 9.44 | 12.10 | 14.95 |
| Power Input | kW | 1.88 | 2.58 | 3.48 | 4.23 | 5.20 | 3.48 | 4.23 | 5.20 | |
| Current | A | 8.45 | 11.44 | 15.42 | 18.41 | 22.60 | 5.87 | 7.15 | 8.78 | |
| EER | W/W | 2.74 | 2.66 | 2.72 | 2.86 | 2.88 | 2.72 | 2.86 | 2.88 | |
| Rated water flow | m3/h | 1.1 | 1.6 (1.5) | 2.1(1.9) | 2.6 | 3.1 | 2.1(1.9) | 2.6 | 3.1 | |
| Rated voltage /Frequency | V/Hz | 230/50 | 230/50 | 230/50 | 230/50 | 230/50 | 400/50 | 400/50 | 400/50 | |
| Maximum input power | kW | 2.76 (2.53) | 3.45 | 3.95 | 5.75 | 6.21 | 3.95 | 5.75 | 6.21 | |
| Maximum input current | A | 12 (11) | 15.0 | 17.0 | 25.0 | 27.0 | 7.0 | 10.0 | 11.0 | |
| High pressure value cut-off pressure | MPa | 4.5 (4.6) | 4.5 (4.6) | |||||||
| Low pressure valve cut-off pressure | MPa | 0.1(max:2.0) | 0.1(max:2.0，OEG2.1) | |||||||
| Power supply | 220-240V~ /50Hz | 380-415V /3N~ /50Hz | ||||||||
| Brand/Type of Compressor | / | Mitsubishi | Mitsubishi | |||||||
| Compressor Model | / | SVB72FNPMC | SVB72FNPMC | SVB220FLGMC-L | MVB42FCPMC-L | MVB42FCPMC-L | SVB220FLGMC-L | MVB42FCPMC-L | MVB42FCPMC-L | |
| Refrigerant | / | R32 | R32 | R32 | R32 | R32 | R32 | R32 | R32 | |
| Refrigerant | kg | 1.5 | 2.25 | 2.7 | 3.6 | 3.6 | 2.7 | 3.6 | 3.6 | |
| Air flow | m3/h | 3500 | 4000 | 4500 | 7600 | 7600 | 4500 | 7600 | 7600 | |
| Brand of Fan motor (DC fan) | KAIBANG/ZWS75-A | LT/RD120HE | KAIBANG/ZWS75-A*2 | LT/RD120HE | KAIBANG/ZWS75-A*2 | |||||
| Fan output | W | 75 | 75 | 120 | 75*2 | 120 | 75*2 | |||
| Brand of Water pump | WILO | WILO | WILO | WILO | WILO | WILO | WILO | WILO | ||
| Water pump Model | Para 15-130/7 | Para 15-130/7 | Para 25-130/8 | Para 25-130/8 | Para 25-130/9 | Para 25-130/8 | Para 25-130/8 | Para 25-130/9 | ||
| Defrost | / | Auto defrost with 4 way valve | ||||||||
| Waterproof grade | / | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | |
| Noise pressure ( at 1M, nameplate 5m) | dB(A) | 51 (35) | 54 (39.5) | 54(44) | 56(41) | 56(41) | 54(44) | 56(41) | 56(41) | |
| Max water outlet temperature | °C | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | |
| Diameter of water connection | / | DN 25 (1") | DN 25 (1") | DN 25 (1") | DN 25 (1") | DN 25 (1") | DN 25 (1") | DN 25 (1") | DN 25 (1") | |
| Drainage valve | mm | 15 | 15 | 15 | 15 | 15 | 15 | 15 | 15 | |
| Internal pressure drop at rating water flow | kPa | 22 (14) | 40(30) | 50(38) | 60 | 60(46) | 50(38) | 60 | 60 | |
| Min/Max heating water pressure (Safety valve 3Bar) | bar | 0.5/3.0 | 0.5/3.0 | 0.5/3.0 | 0.5/3.0 | 0.5/3.0 | 0.5/3.0 | 0.5/3.0 | 0.5/3.0 | |
| Fuse (PCB) | A | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | |
| Lowest Operational point, outdoor air/flow line (heating mode ) | °C | -15°C | -15°C | -15°C | -15°C | -15°C | -15°C | -15°C | -15°C | |
| Highest Operational point, outdoor air/flow line (heating mode ) | °C | 45°C | 45°C | 45°C | 45°C | 45°C | 45°C | 45°C | 45°C | |
| Lowest Operational point, outdoor air/flow line (cooling mode ) | °C | 10°C | 10°C | 10°C | 10°C | 10°C | 10°C | 10°C | 10°C | |
| Highest Operational point, outdoor air/flow line (cooling mode ) | °C | 45°C | 45°C | 45°C | 45°C | 45°C | 45°C | 45°C | 45°C | |
| Net Dimensions ( L/W/H ) | mm | 1115/415/898 | 1115/415/898 | 1115/415/982 | 1115/415/1332 | 1115/415/1332 | 1115/415/982 | 1115/415/1332 | 1115/425/1310 | |
| Package Dimensions ( L/W/H ) | mm | 1155/500/1035 | 1155/500/1035 | 1155/500/1120 | 1155/500/1460 | 1155/500/1460 | 1155/500/1120 | 1155/500/1460 | 1155/500/1460 | |
| Net Weight | kg | 80 | 82 | 105 | 140 | 140 | 105 | 140 | 140 | |
| Gross Weight | kg | 100 | 102 | 120 | 155 | 155 | 120 | 155 | 155 | |
| Loading quantity 20GP/40GP,40HQ | pcs | 44/96/96 | 44/96/96 | 44/96/96 | 22/48/48 | 22/48/48 | 44/96/96 | 22/48/48 | 22/48/48 | |
