Model: | Master plus 60 | Master plus 90 | Master plus 120 | Master plus 160 | ||
Heating Capacity Range | kW | 1.5-7 | 2-10 | 3-13 | 4-18 | |
Heating (A7/6℃,W30/35℃) |
Heating Capacity | kW | 6.3 | 9.5 | 12.1 | 16.2 |
Power Input | kW | 1.36 | 2.03 | 2.63 | 3.51 | |
Current | A | 5.91 | 8.83 | 11.43 | 15.26 | |
COP | W/W | 4.63 | 4.68 | 4.60 | 4.62 | |
Heating (A7/6℃,W47/55℃) |
Heating Capacity | kW | 6.1 | 8.70 | 11.50 | 15.63 |
Power Input | kW | 2.08 | 3.13 | 4.05 | 5.56 | |
COP | W/W | 2.93 | 2.78 | 2.84 | 2.81 | |
Cooling (A35/24℃,W23/18℃) |
Cooling Capacity | kW | 6.3 | 9.20 | 11.30 | 16.02 |
Power Input | kW | 1.62 | 2.41 | 2.95 | 4.16 | |
EER | W/W | 3.89 | 3.82 | 3.83 | 3.85 | |
Cooling (A35/24℃,W12/7℃) |
Cooling Capacity | kW | 6.2 | 8.60 | 10.60 | 15.75 |
Power Input | kW | 2.1 | 2.92 | 3.58 | 5.56 | |
EER | W/W | 2.95 | 2.95 | 2.96 | 2.83 | |
Rated water flow | m3/h | 1.1 | 1.6 | 2.1 | 2.8 | |
Rated voltage /Frequency | V/Hz | 220~240/50 | 220~240/50 | 220~240/50 | 220~240/50 | |
Maximum input power | kW | 2.80 | 3.50 | 4.70 | 6.60 | |
Maximum input current | A | 12.0 | 15.0 | 20.0 | 28.0 | |
Brand/Type of Compressor | / | Mitsubishi/Rotary | HIGHLY/Rotary | HIGHLY/Rotary | HIGHLY/Rotary | |
Refrigerant | / | R290 | R290 | R290 | R290 | |
Air flow | m3/h | 3500 | 4000 | 4500 | 8000 | |
Brand of Water pump | WILO | WILO | WILO | WILO | ||
Waterproof grade | / | IPX4 | IPX4 | IPX4 | IPX4 | |
Noise pressure ( at 1m/5m) | dB(A) | 51/37 | 53/39 | 54/40 | 56/42 | |
Max water outlet temperature | °C | 75 | 75 | 75 | 75 | |
Min/Max outdoor air (heating mode ) | °C | -25/45 | -25/45 | -25/45 | -25/45 | |
Min/Max outdoor air (cooling mode ) | °C | 15/45 | 15/45 | 15/45 | 15/45 | |
Net Dimensions ( L/W/H ) | mm | 965/445/692 | 1106/445/823 | 1106/445/823 | 1106/445/1591 | |
Net Weight | kg | 80 | 90 | 108 | 168 | |
Loading quantity 20GP/40GP,40HQ | pcs | 72/156/156 | 48/104/104 | 48/104/104 | 24/52/52 |
