| Model No. | SWM-03TA1 | SWM-04TA1 | SWM-05TA1 |
|---|---|---|---|
| Power Supply | 220V～240V/1/50Hz | ||
| Heating Capacity at Air 26℃,Water 26℃ Hygro 80% | |||
| Heating Capacity（W) | 3050 | 4000 | 5210 |
| Power Input（W) | 560 | 735 | 951 |
| COP | 5.45 | 5.44 | 5.48 |
| Heating Capacity at Air 15℃,Water 26℃ Hygro 70% | |||
| Heating Capacity（kW) | 2510 | 3180 | 4250 |
| Power Input（kW) | 554 | 686 | 934 |
| COP | 4.53 | 4.52 | 4.55 |
| Max Power Input（kW) | 950 | 1280 | 1550 |
| Max Current(A) | 4.4 | 5.8 | 7.0 |
| Refrigerant | R32 | R32 | R32 |
| Heat Exchanger | Titanium | Titanium | Titanium |
| Air Flow Direction | Horizotal | Horizotal | Horizotal |
| Water Flow Volume（m3/h) | 1.5 | 2.0 | 2.5 |
| Net Dimensions(L*W*H)（mm） | 400*285*350 | 400*285*350 | 400*285*400 |
| Package Dimensions(L*W*H)（mm） | 460*370*400 | 460*370*400 | 460*370*450 |
| Working temperature range（℃） | 8～43 | 8～43 | 8～43 |
| Noise（dB) | 28 | 28 | 29 |
| Net Weight（kg） | 20 | 21 | 23 |
| Gross Weight（kg） | 22 | 23 | 25 |
| 20GP container loading quantity | 400 | 400 | 400 |
| 40HQ container loading quantity | 960 | 960 | 800 |
