Model No. | SWG-07TF1 | SWG-10TF1 | SWG-13TF1 | SGW-17TF1 | SWG-21TF1 | SWG-30TF1 | SWG-30TF3 | SWG-35TF1 |
Advised pool volume(m3) |
below 35 | 25~40 | 35~50 | 50~70 | 60~80 | 80~110 | 80~110 | 100~150 |
Heating Capacity at Air 26℃, Humidity 80%, Water 26℃ in, 28℃ out | ||||||||
Heating Capacity (kW) |
7.76~1.76 | 10.55~2.40 | 13.61~3.09 | 17.15~3.88 | 21.41~4.85 | 30.01~6.81 | 30.05~6.84 | 35.62~8.26 |
Power Input (kW) |
1.12~0.11 | 1.52~0.15 | 1.95~0.19 | 2.46~0.24 | 3.08~0.30 | 4.30~0.42 | 4.30~0.42 | 5.10~0.51 |
COP | 15.75~6.94 | 15.84~6.95 | 16.12~6.98 | 15.96~6.98 | 15.95~6.96 | 16.11~6.98 | 16.14~6.99 | 16.12~6.98 |
Heating Capacity at Air 15℃, Humidity 70%, Water 26℃ in, 28℃ out | ||||||||
Heating Capacity (kW) |
5.76~1.30 | 7.85~1.78 | 10.12~2.29 | 12.78~2.89 | 15.91~3.59 | 22.05~4.98 | 22.14~4.99 | 28.52~6.62 |
Power Input (kW) |
1.16~0.17 | 1.58~0.23 | 2.03~0.30 | 2.57~0.38 | 3.20~0.47 | 4.43~0.65 | 4.44~0.65 | 5.73~0.87 |
COP | 7.57~4.96 | 7.59~4.97 | 7.64~4.99 | 7.63~4.98 | 7.59~4.97 | 7.62~4.98 | 7.63~4.99 | 7.62~4.98 |
Cooling Capacity at Air 35℃, Water 29℃ in, 27℃ out | ||||||||
Cooling Capacity (kW) |
4.28~1.06 | 5.92~1.48 | 7.25~1.82 | 9.47~2.35 | 11.58~2.96 | 15.86~3.91 | 15.89~3.93 | 20.11~4.67 |
Power Input (kW) |
1.15~0.16 | 1.57~0.22 | 1.89~0.26 | 2.51~0.34 | 3.07~0.43 | 4.18~0.56 | 4.17~0.56 | 5.28~0.67 |
EER | 6.61~3.73 | 6.74~3.76 | 6.95~3.83 | 6.89~3.78 | 6.87~3.77 | 6.94~3.79 | 6.98~3.81 | 6.97~3.81 |
Power suply | 220~240V / 1/ 50 Hz |
380~415V / 3 / 50 Hz |
220~240V / 1 / 50 Hz |
|||||
Rated Power Input (kW) |
1.2 | 1.6 | 2.1 | 2.6 | 3.2 | 4.4 | 4.4 | 5.7 |
Rated Current(A) | 5.4 | 7.3 | 9.4 | 11.7 | 14.6 | 20.1 | 7.9 | 26 |
Compressor | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
Refrigerant | R32 | R32 | R32 | R32 | R32 | R32 | R32 | R32 |
Heat Exchanger | Titanium | Titanium | Titanium | Titanium | Titanium | Titanium | Titanium | Titanium |
Air Flow Direction | Horizontal | Horizontal | Horizontal | Horizontal | Horizontal | Horizontal | Horizontal | Horizontal |
Water Flow Volume (m3/h) |
2.5 | 3.5 | 4.5 | 5.5 | 6.5 | 9 | 9 | 12 |
Kind of defrost |
by 4 way valve |
by 4 way valve |
by 4 way valve |
by 4 way valve |
by 4 way valve |
by 4 way valve |
by 4 way valve |
by 4 way valve |
Working temperature range(℃) |
-15~43 | -15~43 | -15~43 | -15~43 | -15~43 | -15~43 | -15~43 | -15~43 |
Noise level (dBa) at 1m |
<36~<45 | <37~<46 | <39~<47 | <40~<48 | <41~<49 | <42~<50 | <42~<50 | <42~<50 |
Noise level (dBa) at 10m |
<19~<26 | <20~<26 | <20~<28 | <21~<30 | <23~<31 | <24~<33 | <24~<33 | <24~<33 |
Casing Material | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic | ABS plastic |
Net Dimensions (mm) (L x W x H) |
836*379 *591 |
836*379 *591 |
896*389 *641 |
896*389 *641 |
896*389 *641 |
1056*416 *744 |
1056*416 *744 |
1056*416 *744 |
Package Dimensions (mm) (L x W x H) |
930*400 *716 |
930*400 *716 |
990*435 *750 |
990*435 *750 |
990*435 *750 |
1146*460 *869 |
1146*460 *869 |
1146*460 *869 |
Net Weight(kg) | 42 | 43 | 53 | 54 | 58 | 86 | 86 | 90 |
Gross Weight(kg) | 51 | 53 | 64 | 65 | 69 | 97 | 97 | 101 |
Water Proof Level | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 |
20GP container loading quantity |
102 | 102 | 90 | 90 | 90 | 72 | 72 | 72 |
40HQ container loading quantity |
210 | 210 | 192 | 192 | 192 | 150 | 150 | 150 |
